P2.5 Multi Directional Micro LED Display Panel 600×337.5mm Size ODM
Product Details:
| Place of Origin: | China |
| Brand Name: | Lemass |
| Certification: | RoHS, FCC, CE, CNAS, BIS, SGS |
| Model Number: | P2.5 high-end LED panel cabinet display |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | Cabinet packing (size: L543mm*W191mm*H696mm) |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10KK pixels/month |
|
Detail Information |
|||
| Name: | P2.5 High-end LED Panel Cabinet Display | Size: | 600x337.5mm |
|---|---|---|---|
| Pixel Pitch: | 2.5/2.48mm | Resolution: | 240x136 |
| Features: | High Refresh Rate 3840Hz | Brightness: | ≥600cd/sqm |
| Lamp Type: | SMD 3in1 2121 | Weight: | 6.5±0.1 |
| High Light: | P2.5 Micro LED Display Panel,337.5mm Micro LED Display Panel,ODM micro led panel |
||
Product Description
P2.5 high-end LED panel cabinet display 600*337.5mm MKS system & PSU backup
Description:
An LED wall, also known as an LED wall backdrop, has rapidly gained popularity in today's digital marketplace. Due to the usual poor quality of general LED displays, it is common that after 3-6 months of installation, there will be technical problems such as screen dead spots, black spots, discoloration or partial loss of picture. Nowadays, most of the LED video wall suppliers do not have their own maintenance team and it is not uncommon for users to feel frustrated at this lack of technical support. Therefore, it is very important to choose a professional LED wall supplier that uses only the very best LED walls.
Quick Detail:
· iCool all-round heat dissipation system
· Magnetic installation design
· System & PSU Backup
· Multi-directional adjustment
· All new structural process design
· AI intelligent adjustment system
Specifications:
| Parameter Item | MKS2.5 |
| Pixel Pitch (mm) | 2.5/2.48 |
| Pixel Density (pixels/sqm) | 161,185 |
| Module Resolution | 120x68 |
| Cabinet Resolution | 240x136 |
| Mask | No |
| Lamp Type | SMD 3in1 2121 |
| Module Size (mm) | 300x168.75 |
| Cabinet Size (mm) | 600x337.5x57 |
| Cabinet Weight (kg) | 6.5±0.1 |
| Brightness (cd/sqm) | ≥600 |
| Gray Scale (Bit) | 14 |
| Color Temp (k) | 3000~15000 |
| Perspective (horiz; Vert) ° | 160 ; 145 |
| Uniformity Of brightness | ≥97% |
| Contrast | 5000:01:00 |
| Control System | Synchronous Control |
| Protection Level | Front IP31, Rear IP43 |
| Intelligent Storage | AI Intelligent Storage |
| Frame Frequency (Hz) | 50/60FPS-120FPS |
| Refresh Rate (Hz) | ≥3840 |
| Working Voltage | AC:100~240V(50-60Hz) |
| Power Consumption (W/ m²) | Max:≤600,Ave:≤200 |
| Single Carton Consumption(W) | 120 |
| Lifetime (hrs) | 100,000 |
| Operating Temp (℃) | -10～+40 |
| Storage Temp (℃) | -20～+60 |
| Humidity Range(Rh) | 10%~85%, Non-condensing |
| Pixel Correction | Brightness And Color Correction |
Details about the product:
Applications:
MH is widely used in commercial advertising, shopping malls, large occasions, etc.
